Predictive Roasting Intelligence
The ThermalRoast Curve Analyzer 4.0 provides professional head roasters with granular control over heat transfer dynamics. By measuring environmental temperature (ET), bean temperature (BT), and drum pressure continuously, the analyzer predicts crash or flick anomalies up to 45 seconds before they occur in the drum.
Core System Capabilities
- Sub-Second Sampling Frequency: Probes supply data updates 10 times per second for smooth RoR calculations without signal noise.
- Agtron & Gourmet Scale Color Estimation: Integrated optical reflective sensor measures bean surface hue immediately post-drop.
- Batch Consistency Scoring: Automatically overlay reference master curves and compute statistical variance for quality control compliance.
System Specifications
| Module | Requirement / Parameter |
|---|---|
| Thermocouple Compatibility | K-Type, J-Type, RTD PT100, IR non-contact sensors |
| Sampling Rate | 10 Hz (10 readings per second) |
| Data Protocols | MODBUS RTU, USB Serial, Wi-Fi 6, MQTT API |
| Operating OS Support | macOS, Windows 11, Linux, iOS tablet interface |
Streamlined Workflow Integration
Whether operating a 1kg sample roaster or a 120kg industrial drum roaster, ThermalRoast 4.0 syncs seamlessly with all commercial equipment manufacturers.
