System Overview
The SpectraSort X1 is designed specifically for specialty coffee dry mills and roasteries seeking zero-defect bean lots. Operating with dual-spectrum RGB cameras paired with Short-Wave Infrared (SWIR) sensors, the SpectraSort X1 evaluates individual bean color, surface texture, and internal moisture density simultaneously.
Key Features & Performance Specs
- Dual-Camera Array: Identifies subtle discoloration, including elusive "quakers" (under-ripe beans) and insect damage invisible under standard daylight.
- High-Velocity Pneumatic Ejectors: 128 ultra-fast air nozzles eject defective items without disturbing adjacent high-grade beans.
- Adaptive AI Calibration: Real-time neural network updates learning customized profiles for Gesha, Bourbon, Typica, and process-heavy micro-lots.
- Throughput Capacity: Configurable from 300 kg/hr up to 1,500 kg/hr depending on ejector sensitivity.
Technical Specifications
| Parameter | Specification |
|---|---|
| Optical Resolution | 0.04 mm per pixel dual-camera system |
| Wavelength Spectrum | 400nm - 1700nm (Visible RGB + SWIR) |
| Ejection Latency | < 0.8 milliseconds |
| Power Consumption | 3.2 kW (220V / 50-60Hz) |
| Operational Air Pressure | 0.6 - 0.8 MPa continuous clean dry air |
Integration with Existing Lines
The unit features standardized hopper flanges, easy-clean stainless steel chutes, and Ethernet IP output to integrate live sorting metrics directly with roastery ERP systems.
